Electroprop Voyager

50 h.p. Electric Engine

Air and Water Cooled
Permanent Magnet Dual Stator High Efficiency Electric Motor
Planetary Gearbox with choice of Ratios
72 to 96 VDC
40 KW Peak, 21 KW Continuous
Ducted Forced Air Cooling with Twin Fans
Closed Circuit Water Cooling with Integrated Radiator
Magnetically Coupled Water Pump
Machined Billet Aluminum Controller Plate with Water Cooling Passages
Machined Billet Aluminum Thrust Plate with Water Cooling Passages
Aluminum Faraday's Cage Enclosure for Protection from Lightning
Choice of Throttle
Can be used as a DC Generator coupled to a diesel motor or impeller
Primarily used to replace a 50 h.p. Diesel Sailboat Engine
